Mini Speaker with Mylar Cone

MINI SPEAKER

  1. Home
  2. Products
  3. SPEAKER
  4. MINI SPEAKER
  5. Φ36*H4.6mm
Φ36*H4.6mm
  1. Φ36*H4.6mm
  2. Φ36*H4.6mm
  3. Φ36*H4.6mm
  4. Φ36*H4.6mm
  5. Φ36*H4.6mm

Φ36*H4.6mm

Send Inquiry Live chat
  • Product Detail
Diamater
36MM
Height
4.6MM
Rated Impedance
32Ω
Rated Input Power
0.25W
Max Input Power
1.5W
S.P.L
89dB(0.1W/0.1m) ± 3 dB
at AVE 0.8K 1.0K 1.2K 1.5K Hz
Resonance Frequency (Fo)
650±20%Hz
Frame
SPCC
Magnet
Nd-Fe-B
Diaphragm
PET
Tags:

PREVIOUS：Φ7.5*Φ7.5*H2.5mm

NEXT：Φ12.0*H5.4mm
